پایتون و استخراج، تبدیل و بارگذاری داده ها (ETL) — راهنمای کامل

1from variables import datawarehouse_name
2
3# sql-server (target db, datawarehouse)
4datawarehouse_db_config = {
5  'Trusted_Connection': 'yes',
6  'driver': '{SQL Server}',
7  'server': 'datawarehouse_sql_server',
8  'database': '{}'.format(datawarehouse_name)
9  'user': 'your_db_username',
10  'password': 'your_db_password',
11  'autocommit': True,
12}
13
14# sql-server (source db)
15sqlserver_db_config = [
16  {
17    'Trusted_Connection': 'yes',
18    'driver': '{SQL Server}',
19    'server': 'your_sql_server',
20    'database': 'db1'
21    'user': 'your_db_username',
22    'password': 'your_db_password',
23    'autocommit': True,
24  }
25]
26
27# mysql
28mysql_db_config = [
29  {
30    'user': 'your_user_1',
31    'password': 'your_password_1',
32    'host': 'db_connection_string_1',
33    'database': 'db_1',
34  },
35  {
36    'user': 'your_user_2',
37    'password': 'your_password_2',
38    'host': 'db_connection_string_2',
39    'database': 'db_2',
40  },
41]
42
43# firebird
44fdb_db_config = [
45  {
46    'dsn': "/your/path/to/source.db",
47    'user': "your_username",
48    'password': "your_password",
49  }
50]

1# example queries, will be different across different db platform
2firebird_extract = ('''
3  SELECT fbd_column_1, fbd_column_2, fbd_column_3
4  FROM fbd_table;
5''')
6
7firebird_insert = ('''
8  INSERT INTO table (column_1, column_2, column_3)
9  VALUES (?, ?, ?)
10''')
11
12firebird_extract_2 = ('''
13  SELECT fbd_column_1, fbd_column_2, fbd_column_3
14  FROM fbd_table_2;
15''')
16
17firebird_insert_2 = ('''
18  INSERT INTO table_2 (column_1, column_2, column_3)
19  VALUES (?, ?, ?)
20''')
21
22sqlserver_extract = ('''
23  SELECT sqlserver_column_1, sqlserver_column_2, sqlserver_column_3
24  FROM sqlserver_table
25''')
26
27sqlserver_insert = ('''
28  INSERT INTO table (column_1, column_2, column_3)
29  VALUES (?, ?, ?)
30''')
31
32mysql_extract = ('''
33  SELECT mysql_column_1, mysql_column_2, mysql_column_3
34  FROM mysql_table
35''')
36
37mysql_insert = ('''
38  INSERT INTO table (column_1, column_2, column_3)
39  VALUES (?, ?, ?)
40''')
41
42# exporting queries
43class SqlQuery:
44  def __init__(self, extract_query, load_query):
45    self.extract_query = extract_query
46    self.load_query = load_query
47
48# create instances for SqlQuery class
49fbd_query = SqlQuery(firebird_extract, firebird_insert)
50fbd_query_2 = SqlQuery(firebird_extract_2, firebird_insert_2)
51sqlserver_query = SqlQuery(sqlserver_extract, sqlserver_insert)
52mysql_query = SqlQuery(mysql_extract, mysql_insert)
53
54# store as list for iteration
55fbd_queries = [fbdquery, fbd_query_2]
56sqlserver_queries = [sqlserver_query]
57mysql_queries = [mysql_query]

1# python modules
2import mysql.connector
3import pyodbc
4import fdb
5# variables
6from variables import datawarehouse_name

1def etl(query, source_cnx, target_cnx):
2  # extract data from source db
3  source_cursor = source_cnx.cursor()
4  source_cursor.execute(query.extract_query)
5  data = source_cursor.fetchall()
6  source_cursor.close()
7
8  # load data into warehouse db
9  if data:
10    target_cursor = target_cnx.cursor()
11    target_cursor.execute("USE {}".format(datawarehouse_name))
12    target_cursor.executemany(query.load_query, data)
13    print('data loaded to warehouse db')
14    target_cursor.close()
15  else:
16    print('data is empty')
17
18def etl_process(queries, target_cnx, source_db_config, db_platform):
19  # establish source db connection
20  if db_platform == 'mysql':
21    source_cnx = mysql.connector.connect(**source_db_config)
22  elif db_platform == 'sqlserver':
23    source_cnx = pyodbc.connect(**source_db_config)
24  elif db_platform == 'firebird':
25    source_cnx = fdb.connect(**source_db_config)
26  else:
27    return 'Error! unrecognised db platform'
28
29  # loop through sql queries
30  for query in queries:
31    etl(query, source_cnx, target_cnx)
32
33  # close the source db connection
34  source_cnx.close()

1# variables
2from db_credentials import datawarehouse_db_config, sqlserver_db_config, mysql_db_config, fbd_db_config
3from sql_queries import fbd_queries, sqlserver_queries, mysql_queries
4from variables import *
5# methods
6from etl import etl_process

1def main():
2  print('starting etl')
3
4  # establish connection for target database (sql-server)
5  target_cnx = pyodbc.connect(**datawarehouse_db_config)
6
7  # loop through credentials
8
9  # mysql
10  for config in mysql_db_config:
11    try:
12      print("loading db: " + config['database'])
13      etl_process(mysql_queries, target_cnx, config, 'mysql')
14    except Exception as error:
15      print("etl for {} has error".format(config['database']))
16      print('error message: {}'.format(error))
17      continue
18
19  # sql-server
20  for config in sqlserver_db_config:
21    try:
22      print("loading db: " + config['database'])
23      etl_process(sqlserver_queries, target_cnx, config, 'sqlserver')
24    except Exception as error:
25      print("etl for {} has error".format(config['database']))
26      print('error message: {}'.format(error))
27      continue
28
29  # firebird
30  for config in fbd_db_config:
31    try:
32      print("loading db: " + config['database'])
33      etl_process(fbd_queries, target_cnx, config, 'firebird')
34    except Exception as error:
35      print("etl for {} has error".format(config['database']))
36      print('error message: {}'.format(error))
37      continue
38
39  target_cnx.close()
40
41if __name__ == "__main__":
42  main()
